YASKAWA NX100 Maintenance Manual

5.4 Recommended Spare Parts
5-19
*1 The CPU unit (JZNC-NRK01-1) does not include the control power supply (CPS-420F),
servo control circuit board (SGDR-AXA01A), and robot I/F unit (JZNC-NIF01). Must
be ordered separately if required.
*2 Specify application (Arc, General, Spot, Handling) of key sheet when No.18 "Program-
ming Pendant" is ordered.
Recommended Spare Parts of NX100 for HP3
Rank
Parts
No.
Name Type Manufacturer Qty
Qty
per
Unit
Remarks
A1
Battery ER6VC3N 3.6V TOSHIBA BAT-
TERY CO., LTD.
11
A2
Control Power Sup-
ply Fan
JZNC-NZU01 Yaskawa Electric
Corporation
11
A3
Backside Duct Fan 4715MS-22T-B50-
B00
Minebea Co., Ltd. 2 2
A4
Interior Circulation
Fan
4715MS-22T-B50-
B00
Minebea Co., Ltd. 2 2
A5
Control Power Sup-
ply Fuse
326010 10A 250V Littelfuse 10 2
A6
Brake Fuse SDP50 5A 125V Daito Communi-
cation Apparatus
Co., Ltd.
10 1
A7
24VDC Fuse for I/O 2173.15P 3.15A
250V
Littelfuse 10 2
B8
Control Power Sup-
ply
CPS-420F Yaskawa Electric
Corporation
11
B9
Servo Control Cir-
cuit Board
SGDR-AXA01A Yaskawa Electric
Corporation
11
B10
Control Circuit
Board
JANCD-NCP01 Yaskawa Electric
Corporation
11
B11
Robot I/F Circuit
Board
JANCD-NIF01-1 Yaskawa Electric
Corporation
11
B12
I/O Circuit Board JANCD-NIO01-1 Yaskawa Electric
Corporation
11
B13
Power-ON
Sequence Circuit
Board
JANCD-NTU01-1 Yaskawa Electric
Corporation
11
C14
Robot I/F Unit JZNC-NIF01-1 Yaskawa Electric
Corporation
11
C15
SERVOPACK SGDR-
EA1400NY26
Yaskawa Electric
Corporation
11
C16
Power Supply Con-
tactor Unit
JZRCR-NTU01-1 Yaskawa Electric
Corporation
11
C17
CPU Unit
*1
JZNC-NRK01-1 Yaskawa Electric
Corporation
11
C18
Programming Pen-
dant
*2
JZRCR-NPP01-1 Yaskawa Electric
Corporation
1 1 With 8m cable

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
