5.4 Recommended Spare Parts
5-20
*1 The CPU unit (JZNC-NRK01-1) does not include the control power supply (CPS-420F),
servo control circuit board (SGDR-AXA01A), and robot I/F unit (JZNC-NIF01). Must
be ordered separately if required.
*2 Specify application (Arc, General, Spot, Handling) of key sheet when No.18 "Program-
ming Pendant" is ordered.
Recommended Spare Parts of NX100 for HP6 and EA1400N
Rank
Parts
No.
Name Type Manufacturer Qty
Qty
per
Unit
Remarks
A1
Battery ER6VC3N 3.6V TOSHIBA BAT-
TERY CO., LTD.
11
A2
Control Power Sup-
ply Fan
JZNC-NZU01 Yaskawa Electric
Corporation
11
A3
Backside Duct Fan 4715MS-22T-B50-
B00
Minebea Co., Ltd. 2 2
A4
Interior Circulation
Fan
4715MS-22T-B50-
B00
Minebea Co., Ltd. 2 2
A5
Control Power Sup-
ply Fuse
326010 10A 250V Littelfuse 10 2
A6
Brake Fuse SDP50 5A 125V Daito Communi-
cation Apparatus
Co., Ltd.
10 1
A7
24VDC Fuse for I/O 2173.15P 3.15A
250V
Littelfuse 10 2
A8
Welder I/F board
fuse
0312001.MXP 1A
250V
Littelfuse 10 2 Only for arc weld-
ing
B9
Control Power Sup-
ply
CPS-420F Yaskawa Electric
Corporation
11
B10
Servo Control Cir-
cuit Board
SGDR-AXA01A Yaskawa Electric
Corporation
11
B11
Control Circuit
Board
JANCD-NCP01 Yaskawa Electric
Corporation
11
B12
Robot I/F Circuit
Board
JANCD-NIF01-1 Yaskawa Electric
Corporation
11
B13
I/O Circuit Board JANCD-NIO01-1 Yaskawa Electric
Corporation
11
B14
Power-ON
Sequence Circuit
Board
JANCD-NTU01-1 Yaskawa Electric
Corporation
11
B15
Welder I/F board JANCD-XEW02 Yaskawa Electric
Corporation
1 1 Only for arc weld-
ing
C16
Robot I/F Unit JZNC-NIF01-1 Yaskawa Electric
Corporation
11
C17
SERVOPACK SGDR-EA1400N Yaskawa Electric
Corporation
11
C18
Power Supply Con-
tactor Unit
JZ
RCR-NTU01-1 Yaskawa Electric
Corporation
11
C19
CPU Unit
*1
JZNC-NRK01-1 Yaskawa Electric
Corporation
11
C20
Programming Pen-
dant
*2
JZRCR-NPP01-1 Yaskawa Electric
Corporation
1 1 With 8m cable
To Next Page
