YASKAWA SGDV series User Manual

3 Wiring and Connection
3.1.2 Main Circuit Wire
3-8
 Tools for Crimp Terminals
Model
Tools (by J.S.T. Mfg Co., Ltd.)
Body Head Dies
3.5-6
YHT-2210 – –
R5.5-6
R8-8
R8-10
YHT-8S – –
YPT-150-1 – TD-221, TD-211
R14-10
Body only: YPT-150-1
or
Body: YF-1; Head: YET-150-1
TD-222, TD-211
R22-8 TD-223, TD-212
R38-8
R38-10
TD-224, TD-212
R60-8
R60-10
TD-225, TD-213
100-8
R100-10
CB100-S8
TD-228, TD-214

YASKAWA SGDV series Specifications

General

Series	SGDV
Communication	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Control Modes	Position, Speed, Torque
Protection Features	Overcurrent, Overvoltage, Undervoltage, Encoder error
Ambient Temperature	0°C to 55°C
Cooling Method	Natural cooling or forced air cooling
Voltage	200V, 400V
Weight	Varies depending on model (e.g., 0.6 kg to 10 kg)
