Configuration
LITECOM, Commissioning and maintenance instructions 17.0 | 04.2024 | en 125
Type
Description
Conditional scene recall
There are different types of conditional scene recall. Depending on the configuration the
scene can also be recalled in a zone using a conditional scene recall.
The following steps are required:
1. Create a zone in the Zones app.
2. Create one or more scenes for the zone in the Scenes app.
3. Create a conditional scene recall with a zone as the effective range in the
Conditional scene recall app.
i
Note
For more information see Section Conditional scene recall
Control equipment
You can also control a zone using control equipment (e.g. momentary-action switch,
standard switch).
i
Note
Zones cannot be controlled using the following devices: LM-CIRIA, LM-
EG.
The following steps are required:
1. Create a zone in the Zones app.
2. Address and configure control equipment in the Zones app.
i
Note
As soon as you have created a zone in your LITECOM system, five
standard scenes are enabled in this zone; one standard scene is
automatically stored for the control equipment.
3. Change the standard scenes or create one or more scenes for the zone in the
Scenes app.
4. If you have created new scenes, store these additionally for the control equipment in
the Zones app or the System image app.
i
Note
A description of the System image app can be found in Section System
image .
Table 71: Control types in zones
