10.3 Configuring devices
The devices installed in your LITECOM system can be configured via the system image.
Configuring a device
Path: App overview > System image
1. Navigate to the path.
2. In the left-hand column, select the room containing the device to be configured.
ÜGroups created in the room are displayed in the right-hand column.
3. Tap the arrow to the left of the group containing the device to be configured.
ÜThe devices in this group are displayed.
4. In the right-hand column, select the device to be configured.
ÜThe Configure button is enabled.
5. Tap the Configure button.
ÜThe Configure [xy] view is displayed.
i
Note
[xy] stands for a device type in each case, e.g. Configure TW
luminaire, Configure CIRCLE control unit.
6. Configure the device.
7. Tap the tick mark.
ÜThe settings are saved.
ÜThe System image view is displayed.
8. Tap this button to access the app overview.
i
Note
If the device being configured supports DALI-2, the respective master is displayed in the system
image. To configure the individual instances (input elements), proceed as follows:
1. Select the DALI-2 device in the respective group.
2. Tap the Configure button.
ÜThe Configure [xy] view is displayed.
ÜThe first instance of the device is displayed.
3. Change the instance name (important for presence and daylight linking).
4. Configure the instance. Depending on the type of instance, different configuration options are
available.
5. Use the and buttons to select the next instance to be configured.
ÜThe settings are saved.
6. Tap the tick mark once all instances have been configured.
ÜThe settings are saved.
ÜThe System image view is displayed.
