Configuration
LITECOM, Commissioning and maintenance instructions 17.0 | 04.2024 | en 108
10.6.2 Configuration options
The following sections provide a description of the individual configuration options and additional examples.
· Condition: time
· Condition: scene
· Condition: twilight
· Condition: sunrise/sunset
· Function: all off
· Function: stairwell
Condition: time
The following table provides a description of the individual configuration options:
Effective range (group, room or zone) in which the conditional scene recall
occurs.
Scene recalled by the conditional scene recall.
The time it takes to change from the last value to the defined scene.
Time at which the scene is recalled.
Additional condition that can be added if desired by enabling the tick mark.
Group, room or zone where a specific scene must be enabled in order for
the conditional scene recall to occur.
Scene
(Only for condition Only if in)
Scene that must be enabled in this group/room/zone.
Another additional condition that can be added if Only if in has been
specified. Tap the tick mark to enable the condition.
Group, room or zone where a specific scene must be enabled in order for
the conditional scene recall to occur.
Scene
(Only for condition And when in)
Scene that must be enabled in this group/room/zone.
Table 61: Configuration options – conditional scene recall with condition “time”
