Your LITECOM system
LITECOM, Commissioning and maintenance instructions 17.0 | 04.2024 | en 12
dimmed/brightened
· 2 h
· 3 h
are compatible
EM powerLED PRO EZ-3, 4
W
Non-maintained light
LED
· 1 h
· 2 h
· 3 h
EM converter for LEDs,
converters from 2015 or later
are compatible
EM powerLED PRO DIM SR
45W
Maintained light that
can be switched/
dimmed/brightened
LED
· 1 h
· 2 h
· 3 h
Combined EM LED converter
EM powerLED PRO DIM C
45W
Maintained light that
can be switched/
dimmed/brightened
LED
· 1 h
· 2 h
· 3 h
Combined EM LED converter
EM ready2apply PRO 2W
Non-maintained
light/maintained light
LED
· 1 h
· 2 h
· 3 h
EM LED module for ceiling
installation
Table 5: Supported self-contained emergency luminaires
· per DALI-compliant output, max. 64 DALI addresses or DALI-2 addresses and max. 64 eD addresses
· per DALI-compliant output, guaranteed supply current 200 mA for max. 100 DALI loads
· per DALI-compliant output, max. supply current 250 mA
Line length: LM-Bus
The LITECOM CCD does not have an integrated LM-Bus supply. You need an external bus supply if you wish to
use the LM-Bus in your LITECOM system:
· LM-BV (art. no. 20 975 247)
· LM-BVS35 (art. no. 22 115 026)
LM system limits, including line lengths, depend on the bus supply used.
Line length: DALI control line
i
Note
If the maximum line length is exceeded, the set switching modes may no longer function or it may
no longer be possible to operate the system. However, the emergency lighting function is still
guaranteed.
Conductor cross-section
Maximum DALI line length
2 × 0.75 mm²
150 m
2 × 1.50 mm²
300 m
Table 6: Maximum DALI line length
