Commissioning
LITECOM, Commissioning and maintenance instructions 17.0 | 04.2024 | en 40
The individual addressing wizard steps are briefly described in the following table. The addressing wizard provides
more detailed information.
Step
Description
Add rooms
Add rooms to the system image. The What are rooms and groups?
button can be used to view a short introduction to this topic.
Add groups
Create groups within the rooms. The What are rooms and groups?
button can be used to view a short introduction to this topic.
Address luminaires
Address the luminaires installed in the LITECOM system.
Address motors
Address the motors installed in the LITECOM system.
Address input devices
Address the input devices installed in the LITECOM system. Input
devices include control equipment (LM-CIRIA, CIRCLE control unit,
standard switch, momentary-action switch, remote control), sensors
and input contacts.
Check addressing
The System image view is displayed in this step. Check whether all
required rooms and groups have been added and the devices have
been correctly addressed. The following options are available:
· Add rooms and groups
· Rename rooms, groups and devices
· Delete rooms, groups and devices
i
Note
· If a group is deleted all devices within this group are
also deleted.
· If a room is deleted all groups in this room and all
devices within these groups are also deleted.
· Display RGA address
· Locate devices visually
· Reassign devices
· Configure devices
i
Note
For more information see Section System image
Next steps
The last page of the addressing wizard contains information on the
next steps in the commissioning process for your LITECOM system.
Table 15: Addressing wizard steps
