--Max. 1 mm (0.04 in)
(5 to 13.2 Hz), max.
7 m/s
2
(23 ft/s
2
)
(13.2 to 100 Hz) si-
nusoidal
Vibration (IEC 60068-2)
R0…R5 (ISTA 1A): Displacement, 25 mm
peak to peak, 14200 vibratory impacts
-Vibration (ISTA)
R6…R8ISTA 3E): Random, overall Grms
level of 0.52
R0…R5 (ISTA 1A): Drop, 6 faces, 3 edges
and 1 corner
Not allowedShock/Drop (ISTA)
inmmWeight range
29.97600...10 kg
(0...22 lb)
24.061010...19 kg
(22...42 lb)
18.146019...28 kg
(42...62 lb)
13.434028...41 kg
(62...90 lb)
R6…R8 (ISTA 3E): Shock, incline impact:
1.1 m/s (3.61 ft/s)
Shock, rotational edge drop: 200 mm (7.9
in)
1)
For neutral-grounded TN and TT systems and non-corner grounded IT systems.
2)
For corner-grounded TN, TT and IT systems.
Materials
• PC/ABS 3 mm, color NCS 1502-Y (RAL 9002 / PMS 1C Cool Grey), RAL
9002 and PMS 425 C
• ot-dip zinc coated steel sheet 1.5 to 2.5 mm, thickness of coating 100 mi-
crometers, color NCS 1502-Y
Drive enclosure
Plywood, cardboard and molded pulp. Foam cushions PE, PP-E, bands PP.Package
The main parts of the drive can be recycled to preserve natural resources
and energy. Product parts and materials should be dismantled and separated.
Disposal
Generally all metals, such as steel, aluminum, copper and its alloys, and
precious metals can be recycled as material. Plastics, rubber, cardboard and
other packaging material can be used in energy recovery. Printed circuit
boards and large electrolytic capacitors need selective treatment according
to IEC 62635 guidelines. To aid recycling, plastic parts are marked with an
appropriate identification code.
Contact your local ABB distributor for further information on environmental
aspects and recycling instructions for professional recyclers. End of life
treatment must follow international and local regulations.
Applicable standards
The drive complies with the following standards. The compliance with the European Low
Voltage Directive is verified according to standard EN 61800-5-1.
Technical data 133
