Quick installation and commissioning flowchart
SeeTask
Type designation la-
bel (page 34)
Identify the frame of your drive: R0…R8.
Planning the electrical installa-
tion (page 51)
Plan the installation: select the cables, etc.
Technical data (page 111)
Check the ambient conditions, ratings and required cooling air flow.
Mechanical installation: Unpack-
ing and examining delivery,
frames R0…R2 (page 42), Un-
packing and examining delivery,
frames R3...R4 (page 42), Un-
packing and examining delivery,
frames R5 (page 43), Unpacking
and examining delivery, frames
R6…R8 (page 44).
Unpack and check the drive.
Operation principle and hard-
ware description: Type designa-
tion label (page 34)
Electrical installation: Checking
the compatibility with IT (un-
grounded) and corner-grounded
TN systems (page 66)
If the drive will be connected to an IT (ungrounded) system, check that the
internal EMC filter and ground-to-phase varistor are not connected. If the
drive will be connected to a corner-grounded TN system, check that the in-
ternal EMC filter is not connected.
Mechanical installa-
tion (page 39)
Install the drive on a wall.
Planning the electrical installa-
tion: (page 57)
Route the cables.
Electrical installation: Checking
the insulation of the as-
sembly (page 65)
Check the insulation of the input cable and the motor and the motor cable.
Electrical installation: Connect-
ing the power cables (page 70)
Connect the power cables.
Electrical installation: Connect-
ing the control cables (page 84)
Connect the control cables.
Installation checklist:Installation
checklist of the drive (page 99)
Check the installation.
20 Introduction to the manual
