ABB ACQ80-04 Series User Manual

￭ Frame size R3
1
1
4
2
1
3
14
10
9
8
7
12
11
13
5
6
EMC filter grounding screw (EMC).10
Input voltage connection (L1, L2, L3), motor
connection (T1/U, T2/V, T3/W) and PV input
terminal connection (R-, UDC+).
11
PE connection (power line)12
Earthing connection (motor)13
Fan14
Installation point (4)1
Cover plate2
Cover plate screw3
Control panel4
Control panel connection5
CCA-01 interface6
For LED of normal power supply and failure, see
section LEDs (page 108).
7
I/O connection. See section External control
connecting terminal, Frame size
R3...R5 (page 31).
8
Voltage dependent resistor grounding screw
(VAR)
9
28 Operation principle and hardware description
