1
A
2 3 4 5 6 7 8
B
C
D
E
F
A
B
C
D
E
F
First angle projection. Original drawing made with 3D CAD. Set the correct scale factor when adding dimensions after DWG/DXF conversion.
195 7.68[ ]
203 7.99[ ]
160 6.30[ ]
160 6.30[ ]
257 10.13[ ]
619 24.37[ ]
98 3.86[ ]
2pcs
8 .32[ ]
15 .59[ ]
12,5 .49[ ]
Lifting point
2pcs
16 .63[ ]
9,6 .38[ ]
19,6 .77[ ]
17,5 .69[ ]
7,2 .28[ ]
15 .59[ ]
7,4 .29[ ]
17,5 .69[ ]
7,2 .28[ ]
154,8 6.094[ ]
204 8.032[ ]
57 2.26[ ]
73 2.89[ ] 25 .98[ ]
9,6 .378[ ]
123 4.86[ ]
636 25.039[ ]
3AXD50000037264 A.1+
We reserve all rights in this document and in the information contained therein. Reproduction,
use or disclosure to third parties without express authority is strictly forbidden.
© ABB Oy. PROPRIETARY AND SECRET INFORMATION. CONFIDENTIAL
ACS530_R4_MAIN_ASSEMBLY (ASSEM) A.0+
Based on Prepared
Peng Du 28-Sep-16
Title
ASSEMBLY DRAWING
Doc. des. Scale Form
Customer Check.
Hui Xu 28-Sep-16 R4 DIMENSION DRAWINGS
ASSEMBLY DRAWING 1:5 A3
Appr.
Henry Hua-Zhao 28-Sep-16 ACS530 R4
Resp.dept. Rev.ind.
A (AP)
Lang.
EN
Cust. Doc. No. Project name Doc. No.
3AXD50000037264
Sheet
1
DMS Number
3AXD10000490619
Weight kg
20.00
Total
1
A
Initial Approval 28-Sep-16 Peng Du 500000764943
Gen Tol:
ISO 2768-m
Frame R4,IP20
A
B
A
2:5
B
2:5
