• External wiring can supply dangerous voltages to the relay outputs of the control units
of the drive.
• The Safe torque off function does not remove the voltage from the main and auxiliary
circuits. The function is not effective against deliberate sabotage or misuse.
Optical components
WARNING!
Obey these instructions. If you ignore them, damage to the equipment can occur.
• When you unplug the fibre optic cables, always hold the connector, not the cable itself.
• Do not touch the ends of the fibers with bare hands as the ends are extremely sensitive
to dirt.
• Do not bend the fiber optic cables too tightly. The minimum allowed bend radius is
35 mm (1.4”).
Printed circuit boards
WARNING!
Use a grounding wrist band when you handle printed circuit boards. Do not touch
the boards unnecessarily. The boards contain components sensitive to electrostatic
discharge.
￭ Grounding
These instructions are for all personnel who are responsible for the grounding of the drive.
WARNING!
Obey these instructions. If you ignore them, injury or death, or equipment
malfunction can occur, and electromagnetic interference can increase.
• If you are not a qualified electrician, do not do grounding work.
• Always ground the drive, the motor and adjoining equipment. This is necessary for the
personnel safety. Proper grounding also reduces electromagnetic emission and
interference.
• Make sure that the conductivity of the protective earth PE conductors is sufficient. See
the electrical planning instructions of the drive. Obey the local regulations.
• Connect the power cable shields to protective earth terminals of the drive to make sure
of personnel safety.
• Make a 360° grounding of the power and control cable shields at the cable entries to
suppress electromagnetic disturbances.
• In a multiple-drive installation, connect each drive separately to the protective earth
(PE) busbar of the power supply.
Note:
• You can use power cable shields as grounding conductors only when their conductivity
is sufficient.
• IEC/EN 61800-5-1 (section 4.3.5.5.2.) requires that as the normal touch current of the
drive is higher than 3.5 mA AC or 10 mA DC, you must use a fixed protective earth (PE)
connection. The minimum size of the protective earthing conductor must comply with
the local safety regulations for high protective earthing conductor current equipment.
Safety instructions 15
