ABB ACQ80-04 Series User Manual

BIO-01 I/O extension module
Contents of this chapter
This chapter contains a description and technical data of the optional BIO-01 I/O extension
module. The chapter also contains references to the relevant other content elsewhere in
the manual.
Note:
BIO-01 I/O extension module is applicable only for R0...R2 frames.
Safety instructions
WARNING!
Obey the instructions in Safety instructions (page 11). If you ignore them, injury
or death, or damage to the equipment can occur.
BIO-01 product overview
The BIO-01 front option module (Option +L515) is an I/O extension module for R0...R2
frames and can also be used with any of the fieldbus optional module. The BIO-01 I/O
extension module provides:
• three additional digital inputs (DI3, DI4 and DI5)
• one analog input (AI1), and
• one digital output (DO1).
The digital output (DO1) is referred as DIO1 in the firmware. This works only in output mode.
You can also use DI4 and DI5 as frequency inputs and DO1 as a frequency output.
BIO-01 terminal block is removable and uses spring clamps for assembly.
