1
A
2 3 4 5 6 7 8
B
C
D
E
F
A
B
C
D
E
F
First angle projection. Original drawing made with 3D CAD. Set the correct scale factor when adding dimensions after DWG/DXF conversion.
7 .28[ ]
120 4.72[ ]
174,6 6.87[ ]
194,1 7.64[ ]
203 7.99[ ]
719 28.32[ ]
35 1.378[ ]
Lifting point
4pcs
16 .630[ ]
16 .630[ ]
16 .630[ ]
580 22.835[ ]
18 .709[ ]
122 4.803[ ]
R2 .079[ ]
12 .474[ ]
8 .315[ ]
21,5 .846[ ]
7 .276[ ]
15 .591[ ]
8 .315[ ]14 .553[ ]
160 6.299[ ]
98 3.858[ ]
7 .276[ ]
8 .315[ ]581 22.874[ ]
612 24.094[ ]
7 .276[ ]
35 1.38[ ]
123
4.86[
]
25 .98[ ]
73
2.89[
]
296 11.66[ ]
160 6.299[ ]
3AXD50000037291 A.0+
We reserve all rights in this document and in the information contained therein. Reproduction,
use or disclosure to third parties without express authority is strictly forbidden.
© ABB Oy. PROPRIETARY AND SECRET INFORMATION. CONFIDENTIAL
ACS530_R5_MAIN_ASSEMBLY (ASSEM) A.0+
Based on Prepared
Peng Du 10-Oct-16
Title
ASSEMBLY DRAWING
Doc. des. Scale Form
Customer Check.
Hui Xu 10-Oct-16 R5 DIMENSION DRAWING
ASSEMBLY DRAWING 1:5 A3
Appr.
Henry Hua-Zhao 10-Oct-16 ACS530 R5
Resp.dept. Rev.ind.
A (AP)
Lang.
EN
Cust. Doc. No. Project name Doc. No.
3AXD50000037291
Sheet
1
DMS Number
3AXD10000490655
Weight kg
63408937.06
Total
1
A
Initial Approval 10-Oct-16 Peng Du 500000764946
FRAME R5 IP20
B
Lifting point
(2pcs.)
A
A
1:2
B
1:2
