￭ R6...R8
Electrical installation 101
R6…R8
0.5...0.6 N·m
(0.4 lbf·ft)
0.5...0.6 N·m
(0.4 lbf·ft)
M4×20
4
6
10
3
4
4
5
7
8
9
8
11
11
Option modules
You can install the following optional modules:
Applicable framesOption slotModule
R0...R2Front option slot 1I/O extension - BIO-01
R0...R8Front option slot1Fieldbus (In R0...R2 frames, fieldbus
module can be also used with BIO-01
module)
￭ To install a front option
WARNING!
Obey the instructions in chapter Safety instructions (page 11). If you ignore them,
injury or death, or damage to the equipment can occur.
Electrical installation 93
11
