EMC filter grounding screw (EMC).
R0…R2: on the left side of drive.
10
Input voltage connection (L1, L2, L3).11
Motor connection (T1/U, T2/V, T3/W) and PV
input terminal connection (UDC+, UDC-).
12
PE connection (power line)13
Earthing connection (motor)14
Other earthing connections15
Fan16
Cable bundle installation position of I/O cable17
Installation point (4)1
Cover plate2
Cover plate screw3
Control panel4
Control panel connection5
CCA-01 interface6
For LED of normal power supply and failure, see
section LEDs (page 108).
7
I/O connection. See section External control
connecting terminal, Frame size
R0…R2 (page 30).
8
Voltage dependent resistor grounding screw
(VAR)
9
Operation principle and hardware description 27
