R3132 Series Spectrum Analyzer Operation Manual
3.3.4 CONFIG Key (Configuration)
3-26
Copy Device PRT/FD Switches between PRT (printer) and FD (floppy disk) for the
Copy Device.
PRT: Sets the destination to printer.
FD: Selects floppy disk.
Change Title Changes the title previously entered.
10M Ref INT/EXT Switches between internal signals (INT) and external signals
(EXT) for 10 MHz reference frequency output.
INT: Internal signals are used.
EXT: Use the 10 MHz REF IN terminal as the external input
signal source.
CAUTION:
1. EXT is automatically displayed when the external signal is
detected.
2. When the external signal is not detected, EXT is automatically
changed to INT.
Annotation ON/OFF Toggles the annotation (comment characters) display function on
or off.
ON: Displays annotations.
OFF: Erases annotations.
Points 1001/501 Switches between 1001 and 501 for horizontal axis trace points.
1001: Sets trace points to 1001 points.
501: Sets trace points to 501 points.
1/2_more Displays the Config menu (2/2).
Format FD Formats a floppy disk.
