R3132 Series Spectrum Analyzer Operation Manual
4.2.9 GPIB Command Codes
4-26
Table 4-4 Sweep
Function Listener Code
Talker Request
Code Output Format
Sweep time SW* SW? Sweep Time
ST* ST? Sweep Time
SWP auto AS AS? 0:Manual
1:Auto
Sweep mode ––– SWM? 0:Normal & Full
1:Normal & Win
20:Single & Full
21:Single & Win
Sweep mode :Normal CONTS
SN
–––
–––
–––
–––
Sweep mode :Single SI
SNGLS
–––
–––
–––
–––
Take Sweep (Used to wait
until the sweep is complete.)
TS ––– –––
Sweep Reset & Start SR ––– –––
Gate Sweep ON
OFF
GTSWP ON
GTSWP OFF
GTSWP? 0:OFF
1:ON
Gate position GTPOS * GTPOS? Time
Gate width GTWID * GTWID? Time
Gate Slope - GTSLP -
GTSLP FALL
GTSLP? 0:+
1:-
Gate Slope + GTSLP +
GTSLP RISE
Gate Source ––– GTSRC? 3:TV-V
4:TV-H
5:EXT
Gate Source EXT Trigger
TV-V
TV-H
GTSRC EXT
GTEX*
GTSRC TVV
GTSRC TVH
GTTVH*
–––
GTEX?
–––
–––
GTTVH?
–––
Level (Real number)
–––
–––
No. (Integer)
External Gate IN ON
OFF
GEX ON
GEX OFF
GEX?
GEXON?
0:OFF
1:ON
0:OFF
1:ON
