R3132 Series Spectrum Analyzer Operation Manual
4.2.9 GPIB Command Codes
4-27
Table 4-5 Trigger
Function Listener Code
Talker Request
Code Output Format
Trigger Mode ––– TRGSRC? 0:Free RUN
1:Line
2:Video
3:TV-V
4:TV-H
5:Ext.
FREE RUN TRGSRC FREE ––– –––
LINE Trigger TRGSRC LINE ––– –––
VIDEO Trigger TRGSRC VIDEO
VI *
–––
VI?
–––
%(Integer)
External Trigger TRGSRC EXT
EX *
–––
EX?
–––
Level (Real number)
TV-V Trigger TRGSRC TVV ––– –––
TV-H Trigger TRGSRC TVH
TVH *
–––
TVH?
–––
No.(Integer)
Trigger Slope +
Trigger Slope -
TRIGSLP+
TRIGSLP RISE
TRIGSLP-
TRIGSLP FALL
TRIGSLP? 0: +
1: -
TV system NTSC
PAL&SECAM
TVHNT
TVHPS
TVSYS? 1: NTSC
0: PAL&SECAM
Trigger Delay TRGDT * TRGDT? Time
