R3132 Series Spectrum Analyzer Operation Manual
4.2.9 GPIB Command Codes
4-37
Table 4-11 Meas (3 of 3)
Function Listener Code
Talker Request
Code Output Format
IM
measurement
IM measurement mode
ON IMM ON IMMON? 0: OFF
OFF IMM OFF 1: ON
Reference wave data read-
out
––– IMMREF? Frequency, Level
Delta frequency readout ––– IMMDF? Delta frequency
Distortion signal data read-
out
––– IMMRES? n<DLM>LL1, LJ1, UL1, UJ1<DLM>...(*1)
Degree setting IMODR * IMODR? Degree (3, 5, 7, 9)
Criteria input
3 rd order IMLS3 * IMLS3? Level
5 th order IMLS5 * IMLS5? Level
7 th order IMLS7 * IMLS7? Level
9 th order IMLS9 * IMLS9? Level
Pass/Fail judgment
ON IMPFC ON IMPFC? 0 : OFF
OFF IMPFC OFF 1 : ON
Average number IMAVG *
IMAVG [ON,] *
IMAVG OFF
IMAVG?
IMAVGON?
Integer (2 to 999)
0: OFF
1: ON
Hi Sens (IM Meas)
ON IMHS ON IMHS? 0 : OFF
OFF IMHS OFF 1 : ON
(*1) n: Result set number corresponding to the degree
LLn: Level difference in the lower frequency signal
LJn: Pass/Fail judgment result for the lower frequency signal
0: Pass
1: Fail
-1: Judgment off
ULn: Level difference for the upper frequency signal
UJn: Pass/Fail judgment result for the upper frequency signal
