R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-124
(6) QP Bandwidth Accuracy
(7) IF Gain Uncertainty
• RBW = 3 MHz
Test Data Specification Result
RBW (Hz)
Span Setting
(Hz)
Min. (Hz)
Measured
Value (Hz)
Max. (Hz) Pass/Fail
1 M 2 M 0.8 M 1.2 M
120 k 200 k 96 k 144 k
9 k 20 k 8.2 k 10.8 k
200 (OPT27) 1 k 160 240
Setting Test Data Specification Result
RBW (Hz)
Reference
Level (dBm)
Min (dB)
Measured
Value (dB)
Max. (dB) Pass/Fail
3 M -1.0 -0.5 +0.5
-2.0 -0.5 +0.5
-3.0 -0.5 +0.5
-4.0 -0.5 +0.5
-5.0 -0.5 +0.5
-6.0 -0.5 +0.5
-7.0 -0.5 +0.5
-8.0 -0.5 +0.5
-9.0 -0.5 +0.5
-10.0 -0.5 +0.5
-20.0 -0.5 +0.5
-30.0 -0.5 +0.5
-40.0 -0.5 +0.5
-50.0 -0.5 +0.5
