R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-125
• RBW = 300 kHz
• RBW = 1 kHz
Setting Test Data Specification Result
RBW (Hz)
Reference
Level (dBm)
Min (dB)
Measured
Value (dB)
Max. (dB) Pass/Fail
300 k -1.0 -0.5 +0.5
-2.0 -0.5 +0.5
-3.0 -0.5 +0.5
-4.0 -0.5 +0.5
-5.0 -0.5 +0.5
-6.0 -0.5 +0.5
-7.0 -0.5 +0.5
-8.0 -0.5 +0.5
-9.0 -0.5 +0.5
-10.0 -0.5 +0.5
-20.0 -0.5 +0.5
-30.0 -0.5 +0.5
-40.0 -0.5 +0.5
-50.0 -0.5 +0.5
Setting Test Data Specification Result
RBW (Hz)
Reference
Level (dBm)
Min (dB)
Measured
Value (dB)
Max. (dB) Pass/Fail
1 k -1.0 -0.5 +0.5
-2.0 -0.5 +0.5
-3.0 -0.5 +0.5
-4.0 -0.5 +0.5
-5.0 -0.5 +0.5
-6.0 -0.5 +0.5
-7.0 -0.5 +0.5
-8.0 -0.5 +0.5
-9.0 -0.5 +0.5
-10.0 -0.5 +0.5
-20.0 -0.5 +0.5
-30.0 -0.5 +0.5
-40.0 -0.5 +0.5
-50.0 -0.5 +0.5
