R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-126
(8) Input Attenuator Switching Accuracy
• For the R3132
• For the R3132N
R3132 Setting Specification Result
Attenuator
(dB)
Reference
Level (dBm)
Measured
Value (dBm)
Min (dB)
Actual
Value (dB)
Max (dB) Pass/Fail
0 -40 -0.3 +0.3
10 -30 -0 (Ref) -
20 -20 -0.3 +0.3
30 -10 -0.3 +0.3
40 0 -0.3 +0.3
50 +10 -0.3 +0.3
R3132N Setting Specification Result
Attenuator
(dB)
Reference
Level (dBm)
Measured
Value (dBm)
Min (dB)
Actual
Value (dB)
Max (dB) Pass/Fail
0 -40 -0.3 +0.3
10 -30 - 0 (Ref) -
20 -20 -0.3 +0.3
30 -10 -0.3 +0.3
40 0 -0.3 +0.3
50 +10 -0.3 +0.3
