R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-128
• For the R3172/82
Measurement a center frequency of 15 GHz
• For the R3172/82
Measurement a center frequency of 18 GHz
R3172/82 Setting
Specification
Result
Switching Accuracy Step to Step Accuracy
Attenuator
(dB)
Reference
Level (dBm)
Spec. (dB)
Actual
Value (dB)
Spec. (dB)
Actual
Value (dB)
Pass/Fail
10 -50 0 (Ref) 0 (Ref) 0
20 -40 ±2.5 ±1.3
30 -30 ±2.5 ±1.3
40 -20 ±2.5 ±1.3
50 -10 ±2.5 ±1.3
60 0 ±2.5 ±1.3
70 +10 ±2.5 ±1.3
R3172/82 Setting
Specification
Result
Switching Accuracy Step to Step Accuracy
Attenuator
(dB)
Reference
Level (dBm)
Spec. (dB)
Actual
Value (dB)
Spec. (dB)
Actual
Value (dB)
Pass/Fail
10 -50 0 (Ref) 0 (Ref) 0
20 -40 ±3.5 ±1.8
30 -30 ±3.5 ±1.8
40 -20 ±3.5 ±1.8
50 -10 ±3.5 ±1.8
60 0 ±3.5 ±1.8
70 +10 ±3.5 ±1.8
