ADVANTEST R3162

R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-148
(16) Span Accuracy
Frequency
Span (Hz)
Center
Frequency
(Hz)
Specification Result
Min. (Hz)
Measured
Value (Hz)
Max. (Hz) Pass/Fail
100 k 1.5 G 79.2 k 80.8 k
1 M 1.5 G 792 k 808 k
10 M 1.5 G 7.92 M 8.08 M
100 M 1.5 G 79.2 M 80.08 M
1 G 1.5 G 792 M 808 M
3 G 1.5 G 2.376 G 2.424 G
Apply for R3162/72/82
10 M 4 G 7.92 G 8.08 M
100 M 4 G 79.2 G 80.8 M
1 G 4 G 792 M 808 M
8 G 4 G 6.336 G 6.464 G
10 M 7.5 G 7.92 M 8.08 M
100 M 7.5 G 79.2 M 80.8 M
Apply for R3172/82
10 M 10 G 7.92 M 8.08 M
100 M 10 G 79.2 M 80.8 M
1 G 10 G 792 M 808 M
10 G 10 G 7.92 G 8.08 G
20 G 10 G 15.84 G 16.16 G
10 M 17 G 7.92 M 8.08 M
100 M 17 G 79.2 M 80.8 M
1 G 17 G 792 M 808 M
Apply for R3182
10 M 28 G 7.92 M 8.08 M
100 M 28 G 79.2 M 80.8 M
1 G 28 G 792 M 808 M
10 M 35 G 7.92 M 8.08 M
100 M 35 G 79.2 M 80.8 M
1 G 35 G 792 M 808 M
30 G 20 G 23.76 G 24.24 G
