ADVANTEST R3162

R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-149
(17) Third Order Intermodulation Distortion
(18) Gain Compression
Center Frequency
(MHz)
Specification Result
Min. (dB)
Measured Value
(dB)
Max. (dB) Pass/Fail
200 N/A -60
1500 N/A -60
2500 N/A -60
Apply for R3162
3600 N/A -60
7500 N/A -60
Apply for R3172
3600 N/A -50
7500 N/A -50
Apply for R3182
3600 N/A -55
7500 N/A -55
Preamplifier
Center Frequency
(MHz)
Specification Result
Min. (dBm)
Measured
Value (dBm)
Max. (dBm) Pass/Fail
Apply for R3132/62/72/82
OFF 200.5 0
ON 200.5 -25
Apply for R3162
OFF 3600.5 0
Apply for R3172/82
OFF 3600.5 -5
Preamplifier
Center Frequency
(MHz)
Specification Result
Min. (dBµV)
Measured
Value (dBµV)
Max. (dBµV) Pass/Fail
Apply for R3132N
OFF 200.5 107
ON 200.5 82
