ADVANTEST R3162

R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-150
(19) Sweep Time Accuracy
(20) Residual Response
• For the R3132
• For the R3132N
• For the R3162/72/82
Sweep Time
Setting (s)
Test Data (s)
Specification Result
Min. (s)
Measured
Value (s)
Max. (s) Pass/Fail
50 45 44.1 45.9
5 4.5 4.41 4.59
500 m 450 m 441 m 459
50 m 45 m 44.1 m 45.9 m
5 m (Option) 4.5 m 4.41 m 4.59 m
500 µ (Option) 450 µ 441 µ 459 µ
50 µ (Option) 45 µ 44.1 µ 45.9 µ
Preamplifier Frequency Range
Specification Result
Min. (dBm)
Measured
Value
Max. (dBm) Pass/Fail
OFF 1 MHz to 3 GHz N/A -100
ON 1 MHz to 3 GHz N/A -105
Preamplifier Frequency Range
Specification Result
Min (dBµV)
Measured
Value
Max. (dBµV) Pass/Fail
OFF 1 MHz to 2.2 GHz N/A 11
ON 1 MHz to 2.2 GHz N/A 6
Preamplifier Frequency Range
Specification Result
Min. (dBm)
Measured
Value
Max. (dBm) Pass/Fail
OFF 1 MHz to 3.3 GHz N/A -100
ON 1 MHz to 3.3 GHz N/A -105
OFF 3.2 MHz to 8 GHz N/A -90
