ADVANTEST R3162

R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-151
(21) Tracking Generator
• Absolute Output Level Accuracy
• Output Level Flatness
Test Data
Specification Result
Min. (dB) Measured Value (dB) Max. (dB) Pass/Fail
-10 dBm -0.5 +0.5
Test Data Specification Result
Center Frequency
(Hz)
Min. (dB) Measured Value (dB) Max. (dB) Pass/Fail
30 M - 0 (Ref.) -
100 k -1.0 +1.0
300 k -1.0 +1.0
1 M -1.0 +1.0
3 M -1.0 +1.0
10 M -1.0 +1.0
100 M -1.0 +1.0
200 M -1.0 +1.0
400 M -1.0 +1.0
600 M -1.0 +1.0
800 M -1.0 +1.0
1 G -1.0 +1.0
1.2 G -1.5 +1.5
1.4 G -1.5 +1.5
1.6 G -1.5 +1.5
1.8 G -1.5 +1.5
2 G -1.5 +1.5
2.2 G -1.5 +1.5
2.4 G -1.5 +1.5
2.6 G -1.5 +1.5
2.8 G -1.5 +1.5
3.0 G -1.5 +1.5
