ADVANTEST R3162

R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-152
• Output Level Switching Accuracy
Setting of R3132/3162 Specification Result
Center
Frequency (Hz)
Output Level
(dBm)
Reference
Level (dBm)
Min. (dB) Max. (dB) Pass/Fail
100 k -10.0 -5.0 N/A Reference N/A
0 5.0 -1.0 +1.0
-14.9 -9.9 -1.0 +1.0
-15.0 -10.0 -1.0 +1.0
-19.9 -14.9 -1.0 +1.0
-20.0 -15.0 -1.0 +1.0
-30.0 -25.0 -1.0 +1.0
-40.0 -35.0 -2.0 +2.0
-50.0 -45.0 -2.0 +2.0
1 M -10.0 -5.0 N/A Reference N/A
0 5.0 -1.0 +1.0
-14.9 -9.9 -1.0 +1.0
-15.0 -10.0 -1.0 +1.0
-19.9 -14.9 -1.0 +1.0
-20.0 -15.0 -1.0 +1.0
-30.0 -25.0 -1.0 +1.0
-40.0 -35.0 -2.0 +2.0
-50.0 -45.0 -2.0 +2.0
10 M -10.0 -5.0 N/A Reference N/A
0 5.0 -1.0 +1.0
-14.9 -9.9 -1.0 +1.0
-15.0 -10.0 -1.0 +1.0
-19.9 -14.9 -1.0 +1.0
-20.0 -15.0 -1.0 +1.0
-30.0 -25.0 -1.0 +1.0
-40.0 -35.0 -2.0 +2.0
-50.0 -45.0 -2.0 +2.0
