AGFA SelectSet Avantra - Page 113

Figure 6.2. Bridge for the on-line processor. ➀ —Top cover. ➁ —Bottom cover.
Figure 6.3. Locations on the bridge media path.
➀ —Media slot. ➁ —Lower section.
➂ —Top section. ➃ —Entrance to media processor.
➀
➁


➀
➁
➂
➃
6–12 • SelectSet Avantra User Guide
