AGFA SelectSet Avantra - Switches and Sensors

Switches and Sensors
The following illustration provides you with the locations of various
Switches and Sensors for use with Status and Error Messages.
Figure 9.2. The Switches and Sensors
➀
➁
➂
➅
➇
➈
➃
➄ ➆
➀ Imagesetter
➁ Bridge
➂ Processor
➃ Processor Offline Sensor
➄ OLP input sensor
➅ OLP Input rollers
➆ OLP Input out sensor
➇ Door Open Switch
➈ Exit Sensor
9–28 • Avantra User Guide
