Figure 8.1. Exterior view of the SelectSet Avantra and OLP
Figure 8.2. Cutaway view of the SelectSet Avantra and OLP showing the media path.
➀ —Imagesetter. ➁ —Bridge. ➂ —Processor.
➀
➁
➂
Avantra 20/25 OLP Bridge Operation • 8–3
