Figure 8.3. Cutaway view showing key parts of the media path through the bridge.
➃
➄
➅
➆
➀
➁
➂
➀ Imagesetter.
➁ Bridge.
➂ Processor.
➃ Nip rollers and cutter.
➄ Bridge entry sensor.
➅ Bridge center sensor.
➆ Bridge to processor
mechanical interface.
Avantra 20/25 OLP Bridge Operation • 8–9
