126 Installation, Operation, and Maintenance
Part 2, Operation
6 Vials and Bottles
Using a single solvent bottle of each type, all four waste bottles must be used;
41 vials can be run. Using two solvent A bottles and two solvent B bottles,
84 vials can be run. If you use three solvent A bottles and three solvent B
bottles, you can run 100 vials which is the tray capacity limit.
Table 1 9 For Solvent A and Waste A bottles
Total number of waste or
solvent bottles
Sample vials/Waste
bottles
Sample vials/Solvent vial
1NA41
2 100 84
3NA100
Table 2 0 For Solvent B and Waste B bottles
Total number of waste or
solvent bottles
Sample vials/Waste
bottles
Sample vials/Solvent vial
1NA62
2 100 100
3NA100
CAUTION
We strongly recommend that all waste positions in all turrets contain bottles at all
times, regardless of which ones are actually used in the current configuration. This
protects against accidental discharge of solvent into the turret body, which could
damage it.
