A Accessories and platepads
Setting up the Thermal Station (cooling pad)
152
Bravo Platform User Guide
Setup workflow
Installing the Thermal Station
Before you start
Make sure you have the following:
• Thermal Station (cooling pad), including the adapter pad and socket-head screw
that fastens the adapter pad to the deck
• Hex wrenches: M1.5, M2, and M5
• Plumber’s tape
• Liquid chilling unit, tubing, and manufacturer user documentation
To prevent a potential injury, turn off the Bravo Platform before you install or remove
the accessory.
Procedure
To install the Thermal Station:
1 Ensure that the platepad is removed from the target deck location.
To remove the platepad, uninstall the M6 screw in the center of the platepad and
then lift the platepad off of the deck.
2 Prepare the aluminum adapter pad, as follows:
a Install the elbow plug (part G5550-24200) with plumber’s tape in the drain hole
on the adapter pad.
b Set the plug angle slightly lower than parallel to the pad to allow draining.
Step Procedure See…
1 Install the Thermal Station at the Bravo
deck location.
“Installing the Thermal Station”
on page 152
2 Edit the teachpoint.
Note: Earlier model thermal pads may not
have a crosshairs. In this case, use the
teach plate. Be sure to consider the
10-mm thickness of the teach plate when
you edit the teachpoint.
“Setting the first teachpoint” on
page 36
3 Complete the hardware setup. “Completing the hardware
setup” on page 154
