Network QoS Policies
7210 SAS D, E, K OS Quality of Service Guide Page 121
DSCP Marking CPU Generated Traffic
DSCP marking for CPU generated traffic is not configurable by the user. The default values are
given in Table 32:
Note: DSCP and Dot1P values in the table are applicable when remarking is disabled at port level.
Table 32: DSCP and Dot1p Marking
Protocol IPv4
DSCP
Marking
Dot1P
Marking
Default
FC
DSCP
Values
DOT1P
Values
SNMP Yes Yes Yes H2 34 4
NTP Yes Yes Yes NC 48 7
TELNET Yes Yes Yes H2 34 4
FTP Yes Yes Yes H2 34 4
TFTP Yes Yes Yes H2 34 4
SYSLOG Yes Yes Yes H2 34 4
TACACS Yes Yes Yes H2 34 4
RADIUS Yes Yes Yes H2 34 4
SSH Yes Yes Yes H2 34 4
ICMP Req Yes Yes Yes NC 0 7
ICMP Res Yes Yes Yes NC 0 7
ICMP Unreach Yes Yes Yes NC 0 7
SCP Yes Yes Yes H2 34 4
STP NA NA Yes NC - 7
CFM NA NA Yes NC - 7
ARP NA NA Yes NC - 7
SNMP trap/log Yes Yes Yes H2 34 4
ICMP ping Yes Yes Yes NC 0 7
Trace route Yes Yes Yes NC 0 7
TACPLUS Yes Yes Yes H2 34 4
