QoS Policies
7210 SAS D, E, K OS Quality of Service Guide Page 53
Table 14: Service Ingress QoS Policy IPv6 Match Criteria for 7210 SAS-D and 7210 SAS-E
Table 15: Service Ingress QoS Policy MAC Match Criteria for 7210 SAS-D and SAS-E
The MAC match criteria that can be used for an Ethernet frame depends on the frame’s format.
Note that 7210 SAS-D and SAS-E does not support configuring of the frame-type match criteria
and the default frame type configured is Ethernet – II. See Table 16, MAC Match Ethernet Frame
Types, on page 60
Table 13: Service Ingress QoS Policy IP Match Criteria for 7210 SAS-D and SAS-E
IP Criteria
• IP DSCP and IP Precedence value (available for
access SAPs in VPLS and VLL services)
IP source and mask, IP destination
and mask, IP protocol, TCP/UDP
source port, TCP/UDP destination
port, (available only for access
SAPs in VPLS and VLL services)
IPv6 Criteria
• IP DSCP and IP Precedence value (available for SAPs
in VPLS and VLL services)
IPv6 128-bit source and mask, IPv6
128-bit destination and mask, IP
protocol/next-header, TCP/UDP
source port, TCP/UDP destination
port, (available only for SAPs in
VPLS, and VLL services)
MAC Criteria
• IEEE 802.1p/Dot1p value/mask, Source MAC
address/mask, Destination MAC address/mask,
EtherType Value/Mask (available for VLL, VPLS,
and R-VPLS services.
