QoS Policies
7210 SAS D, E, K OS Quality of Service Guide Page 51
Table 12: Default Service Ingress Policy ID 1 Definition for 7210 SAS-K
Service Ingress Classification
Mapping flows to forwarding classes is controlled by comparing each packet to the match criteria
in the Service Ingress QoS policy. The ingress packet classification to forwarding class is subject
to a classification policy provisioned.
Service Ingress Classification on 7210 SAS-D and 7210 SAS-E
On 7210 SAS-D and 7210 SAS-E devices, on SAP ingress user has an option to use either MAC
criteria or IP criteria or both IPv4 and MAC. To allow users to use the available classification
resources effectively the following options are available:
• Supported MAC header fields using the mac-criteria any option.
• Only Dot1p bits in the MAC header using the mac-criteria dot1p-only option.
• Supported IPv4 header fields using the ip-criteria any option.
• Only IPv4 DSCP in the IPv4 header using the ip-criteria dscp-only option.
• Supported IPv6 header fields using the ipv6-criteria any option.
• Only IPv6 DSCP bits in the IPv6 header using the ipv6-criteria dscp-only option.
Among the above supported criteria the following can be configured together in a single policy:
• mac-criteria any
• mac-criteria dot1p-only
• ip-criteria any and/or ipv6-criteria any or ipv6-criteria dscp-only
Characteristic Item Definition
Queue Queue 1 1 (one) queue all unicast traffic and multicast traffic:
• Forward Class: best-effort (be)
• CIR = 0
• PIR = max
• MBS = 60
• CBS = 10
• Priority= 1
• Weight= 1
Flows Default Forwarding
Class (be)
1 (one) flow defined for all traffic:
• All traffic mapped to best-effort (be)
