Network QoS Policies
7210 SAS D, E, K OS Quality of Service Guide Page 141
Network QoS Policies Resource Usage Examples for 7210 SAS-D and 7210
SAS-E
Example 1
network 1 create
description “default QoS policy”
ingress
default-action fc be profile out
meter 1 create
exit
meter 9 multipoint create
exit
exit
egress
fc af
exit
fc be
exit
fc ef
exit
fc h1
exit
fc h2
exit
fc l1
exit
fc l2
exit
fc nc
exit
exit
The number of classification entries (TC) used is calculated, as follows:
(2 * 0)nc + (2 * 0)h1 + (2 * 0)ef + (2 * 0)h2 + (2 * 0)l1 + (2 * 0)af + (2 * 0)l2 + (2 * 1)be = 18
The number of meters (TP) used are: 2 (meter 1 and 9).
Example 2
network 2 create
description “network-policy-2”
ingress
default-action fc be profile out
meter 1 create
exit
meter 2 create
exit
