Remark Policies for 7210 SAS-K devices
7210 SAS D, E, K OS Quality of Service Guide Page 449
dscp service egress policy Access SAP egress • IP DSCP bits in the IP
header (if present) for ser-
vice packets sent out of an
Access SAP.
Network policy Access-uplink Port • IP DSCP bits in the IP
header (if present) for ser-
vice packets sent out of an
Access-uplink port Mark-
ing is done for packets sent
out of all the access-uplink
SAPs configured on the
access-uplink port.
dot1p-dscp service egress policy Access SAP egress • Dot1p bits and optionally
the DEI bits, in the L2
header for service packets
sent out of access SAP. In
addition to the dot1p bits,
the IP DSCP bits in the IP
header (if present) are
marked for service packets
sent out of an Access SAP.
Network policy Access-uplink Port • Dot1p bits and optionally
the DEI bits, in the L2
header for service packets
sent out of access uplink
port. In addition to the
dot1p bits, the IP DSCP
bits in the IP header (if
present) are marked for ser-
vice packets sent out of an
access-uplink port. Mark-
ing is done for packets sent
out of all the access-uplink
SAPs configured on the
access-uplink port.
Table 48: Summary of remark policy and attachment points for 7210 SAS-K
Remark Policy
Type
Qos Policy Attachment Point Packet Header Bits Marked
