7705 SAR OS Services Guide Page 151
12 16 192 2.000 2 24 0.250
13 16 208 2.000 2 26 0.250
14 16 224 2.000 2 28 0.250
15 16 240 2.000 2 30 0.250
16 8 128 1.000 2 32 0.250
17 8 136 1.000 2 34 0.250
18 8 144 1.000 2 36 0.250
19 8 152 1.000 2 38 0.250
20 8 160 1.000 2 40 0.250
21 8 168 1.000 2 42 0.250
22 8 176 1.000 2 44 0.250
23 8 184 1.000 2 46 0.250
24 8 192 1.000 2 48 0.250
25 8 200 1.000 2 50 0.250
26 8 208 1.000 2 52 0.250
27 8 216 1.000 2 54 0.250
28 8 224 1.000 2 56 0.250
29 8 232 1.000 2 58 0.250
30 8 240 1.000 2 60 0.250
31 8 248 1.000 2 62 0.250
Table 19: Default and Minimum Payload Size for CESoPSN without CAS (Continued)
Default Values Minimum Values
Number of
Timeslots
(N)
Frames
per Packet
(F)
Payload Size
(Octets)
(S)
Packetization
Delay (ms)
(D)
Frames
per Packet
(F)
Payload Size
(Octets)
(S)
Packetization
Delay (ms)
(D)
