Getting Started
7705 SAR OS Services Guide Page 33
16-port T1/E1 ASAP
Adapter card
16 individual T1/E1
ports on the faceplate
The T1/E1 ports on the 7705 SAR-F are equivalent to the
T1/E1 ports on the 16-port T1/E1 ASAP Adapter card, except
that the 16 T1/E1 ports on the 7705 SAR-F support multiple
synchronization sources to support two timing references.
On the 7705 SAR-8, the CLI indicates the MDA type for the
16-port T1/E1 ASAP Adapter card as a16-chds1. On the
7705 SAR-F, the CLI indicates the MDA type for the
7705 SAR-F ports as a16-chds1v2.
8-port Ethernet
Adapter card
8 individual Ethernet
ports on the faceplate
The –48 VDC versions of the 7705 SAR-8 support two
versions of the 8-port Ethernet Adapter card, with version 2
having additional support for Synchronous Ethernet. The
Ethernet ports on the 7705 SAR-F are equivalent to the
Ethernet ports on version 2 of the 8-port Ethernet Adapter
card and support multiple synchronization sources to support
two timing references.
The +24 VDC version of the 7705 SAR-8 only supports
version 2 of the 8-port Ethernet Adapter card.
On the 7705 SAR-8, the CLI indicates the MDA type for the
8-port Ethernet Adapter card as a8-eth or a8-ethv2. On
the 7705 SAR-F, the CLI indicates the MDA type for the
7705 SAR-F Ethernet ports as a8-ethv3, to distinguish it
from the actual version 2 of the 8-port Ethernet Adapter card.
Requires user
configuration at card
(IOM) and MDA
(adapter card) levels
Configuration at card
(IOM) and MDA
(adapter card) levels
is preset and users
cannot change these
types
Table 2: 7705 SAR-8 and 7705 SAR-F Comparison (Continued)
7705 SAR-8 7705 SAR-F Notes
