ALIEN MEGA/MAX USER MANUAL
126
3. Click checkbox to enable UPnP.
4. Select the Mapping Type as Manual or Auto in the drop-down list.
OPTION 1: Auto
If you select Auto, the Port Mapping items are read-only and the external ports
are set by the router automatically.
1) Click Apply button to save the settings.
2) You can click Refresh button to get the latest status of the port mapping.
Figure 9.2.5.2 UPnP Settings Finished-Auto
OPTION 2: Manual
If you select Manual as the mapping type, you can edit the external port by
clicking to activate the External Port Settings dialogue box.
Steps:
1) Click to activate the External Port Settings dialogue box. Configure the
external port No. for server port, http port and RTSP port respectively.
You can use the default port number or change it according to actual
requirements.
External Port indicates the port No. for port mapping in the router.
The value of the RTSP port No. should be 554 or between 1024 and 65535,
while the value of the other ports should be between 1 and 65535 and the
value must be different from each other. If multiple devices are configured
for the UPnP settings within the same router, the port number for each
device should be unique.
Figure 9.2.5.3 External Port Settings Dialogue Box
2) Click Apply button to save the settings.
3) You can click Refresh button to get the latest status of the port mapping.
