ALIEN MEGA/MAX USER MANUAL
128
RTSP Port: The RTSP (Real Time Streaming Protocol) is a network control
protocol designed for use in entertainment and communications systems to
control streaming media servers.
Enter the RTSP port in the text field of RTSP Port. The default RTSP port is
1240 but you can change it according to different requirements.
Server Port and HTTP Port: Enter the Server Port and HTTP Port in the
text fields. The default Server Port is 8240 and the HTTP Port is 80 but you
can change them according to different requirements.
The Server Port should be set to the range of 2000-65535 and it is used for
remote client software access. The HTTP port is used for remote IE access.
Figure 9.2.6.2 Configure More Settings
4. Click the Apply button to save and exit the interface.
9.2.7 Configuring HTTPS Port
Purpose:
HTTPS provides authentication of the web site and associated web server that one is
communicating with, which protects against malware attacks. Perform the following
steps to set the port number of https.
Example:
If you set the port number as 443 and the IP address is 192.168.0.64, you may access
the device by inputting https://192.168.0.64:443 via the web browser.
The HTTPS port can be only configured through the web browser.
Steps:
1. Open web browser, input the IP address of device, and the web server will select
the language automatically according to the system language and maximise the
web browser.
2. Input the correct user name and password, and click Login button to log into the
device.
3. Enter the HTTPS settings interface.
Configuration > Remote Configuration > Network Settings > HTTPS
4. Create the self-signed certificate or authorised certificate.
To Next Page
