ALIEN MEGA/MAX USER MANUAL
45
3.3 Channel-Zero Encoding
This chapter is applicable to MAX316 and MAX416 series only.
Purpose:
Sometimes due to low broadband resources you need to get a remote view of many
channels in real time mode from a web browser or client software, in order to
decrease the bandwidth requirement without affecting the image quality. The
channel-zero encoding facility allows you to display all camera channels on a single
channel display and by clicking on one of the imbedded channels, a full channel
screen display for that channel is displayed.
Steps:
1. Enter the Live View Settings interface.
Menu> Setup> Live View
2. Select the Channel-Zero Encoding tab.
Figure 3.3.1 Live View- Channel-Zero Encoding
3. Click the checkbox after Enable Channel-Zero Encoding.
4. Configure the Frame Rate, Max. Bitrate Mode and Max. Bitrate.
5. Click the Apply button to activate the settings.
After you set the Channel-Zero encoding, you can get a view in CCTVWindow or
web browser, 16 channels on a single channel. When clicking on the imbedded
channel, a full screen display of the channel will be shown.
