ALIEN MEGA/MAX USER MANUAL

Chapter 5 Recording Settings

5.1 Configuring Recording Parameters

Before you start:

1. Make sure that the HDD has already been installed. If not, please install an HDD

and format it. (Menu>Drives>General) Tick box on HDD being formatted.

Figure 5.1.1 HDD- General

2. Click Advance to check the storage mode of the HDD.

1) Whether the HDD mode is Quota, please set the maximum record capacity.

For detailed information, see Chapter 0. Configuring Quota Mode.

2) If the HDD mode is Group, you should set the HDD group. For detailed

information, see Chapter 5.9 Configuring HDD Group for Recording.

Figure 5.1.2 HDD- Advanced

Steps:

1. Enter the Encoding settings interface to configure the encoding parameters:

Menu>Video>Encoding

Figure 5.1.3 Encoding Parameters
