x930 Series Installation Guide for Virtual Chassis Stacking
117
Installing the Switch in an Equipment Rack
To install the switch in a 19-inch equipment rack, perform the following
procedure:
Caution
The chassis may be heavy and awkward to lift. Allied Telesis
recommends that you get assistance when mounting the chassis in
an equipment rack.  E28
Note
The x930 Series switches can be installed in an equipment rack with
the AT-RKMT-SL01 Sliding Rack Mount Kit. For instructions, refer to
the AT-RKMT-SL01 Sliding Rack Mount Kit Installation Guide.
1. Place the unit on a level, secure surface.
2. Attach two of the rack mount brackets to the sides of the switch using
eight of the bracket screws included with the unit. Figure 53 on page
118 and Figure 54 on page 119 illustrate the four possible bracket
positions.
To Next Page
