RJ-45 Style Serial Console Port Pinouts
Table 37 lists the pin signals of the RJ-45 style serial Console port.
Table 37. RJ-45 Style Serial Console Port Pin Signals
Pin Signal
1 Looped to pin 8.
2 Looped to pin 7.
3 Transmit Data
4 Ground
5 Ground
6 Receive Data
7 Looped to pin 2.
8 Looped to pin 1.
