Allied Telesis AlliedWare Plus Installation Guide

x930 Series Installation Guide for Virtual Chassis Stacking
125
Plywood Base for a Wall with Wooden Studs
If you are installing the switch on a wall that has wooden studs, Allied
Telesis recommends using a plywood base to attach the device to the
wall. (A plywood base is not required for a concrete wall.) Refer to
Figure 59.
Figure 59. Switch on the Wall with a Plywood Base
Wall Studs
Wall
Plywood Base
